5G/LTE Interference Solutions: Advanced Filtering Technology
As 5G and LTE networks continue to expand across South Africa, satellite operators face increasing challenges with signal interference. Telemedia is proud to introduce our comprehensive range of 5G/LTE interference filters, designed to protect your satellite communications from unwanted terrestrial signals.
The Challenge
The rollout of 5G networks in the C-band spectrum (3.4-3.8 GHz) creates potential interference with satellite downlink frequencies (3.7-4.2 GHz). This overlap can cause:
- Signal degradation
- Complete loss of satellite reception
- Intermittent service disruptions
- Reduced system performance
Our Solution
Telemedia offers a complete range of professional-grade filters designed to eliminate 5G/LTE interference while maintaining optimal satellite signal quality.
Product Range
1. TM-5G-PLL Series (PLL LNB with Integrated Filter)
- Frequency Range: 3.7-4.2 GHz
- Noise Figure: 17K typical
- Gain: 65 dB
- Filter Rejection: >50 dB @ 3.4-3.8 GHz
- Input VSWR: 1.25:1
- Output VSWR: 1.5:1
- DC Power: 12-24V
- Current Consumption: 180mA typical
2. TM-5G-WG Series (Waveguide Filters)
- Models: WR229, WR137, WR90
- Insertion Loss: <0.3 dB
- Rejection: >60 dB @ 3.4-3.8 GHz
- Power Handling: Up to 500W
- Temperature Range: -40°C to +70°C
- Connectors: Standard waveguide flanges
3. TM-5G-IF Series (In-line Filters)
- Impedance: 50Ω or 75Ω
- Frequency Range: 950-1450 MHz (L-band)
- Insertion Loss: <1.5 dB
- Rejection: >40 dB out of band
- Connectors: N-type or F-type
- Housing: Weather-resistant aluminum
Technical Specifications
Filter Performance Characteristics
| Parameter | TM-5G-PLL | TM-5G-WG | TM-5G-IF |
|---|---|---|---|
| Passband | 3.7-4.2 GHz | 3.7-4.2 GHz | 950-1450 MHz |
| Rejection @ 3.6 GHz | >50 dB | >60 dB | N/A |
| Insertion Loss | <0.5 dB | <0.3 dB | <1.5 dB |
| Return Loss | >20 dB | >23 dB | >18 dB |
| Group Delay | <10 ns | <5 ns | <20 ns |
| Operating Temp | -40°C to +60°C | -40°C to +70°C | -30°C to +60°C |
Mechanical Specifications
| Model | Dimensions (mm) | Weight | Mounting |
|---|---|---|---|
| TM-5G-PLL | 170 x 120 x 85 | 0.8 kg | Feed horn mount |
| TM-5G-WG-229 | 200 x 150 x 100 | 2.1 kg | Flange mount |
| TM-5G-IF-N | 120 x 60 x 40 | 0.3 kg | In-line |
Installation Guidelines
Site Survey
- Identify potential 5G/LTE interference sources
- Measure existing interference levels
- Determine optimal filter placement
- Calculate required rejection levels
Filter Selection
- Urban areas: Recommend TM-5G-WG for maximum rejection
- Suburban areas: TM-5G-PLL provides integrated solution
- Rural areas: TM-5G-IF may be sufficient
Installation Best Practices
- Install filters as close to the antenna as possible
- Ensure proper weatherproofing of all connections
- Use low-loss cables for IF connections
- Verify system performance after installation
Case Studies
Broadcasting Station - Johannesburg
- Problem: Complete signal loss during peak 5G usage
- Solution: TM-5G-WG-229 waveguide filter
- Result: Full signal restoration with <0.3 dB insertion loss
VSAT Network - Cape Town
- Problem: Intermittent connectivity issues
- Solution: TM-5G-PLL integrated LNB/filter
- Result: Stable 24/7 connectivity restored
Benefits
- Plug-and-play installation
- Minimal signal loss in passband
- Weather-resistant construction
- 5-year warranty on all models
- Local technical support
Availability and Pricing
All filters are available from stock with competitive pricing for bulk orders. Contact our sales team for:
- Custom frequency requirements
- OEM integration options
- Installation services
- Technical consultation
Future-Proof Your Satellite Systems
Don't let 5G interference compromise your satellite communications. Our filters provide reliable, long-term protection ensuring your systems continue to operate at peak performance.
Contact Our Technical Team
For technical specifications, installation support, or to discuss your specific requirements:
- Technical Support: support@telemedia.co.za
- Sales Inquiries: sales@telemedia.co.za
- Phone: +27 11 803 3353
Download the complete technical datasheet from our website
